RP-IPG63168IX-4FR


16-P Gigabit + 8-TP/SFP(1G) Combo + 4-SFP(1G/2.5G/10G) slot L2+ Managed Industrial PoE Switch

Model: RP-IPG63168IX-4FR

  • 30W per PoE port, 370W total power
  • Full gigabit downlink, 10G uplink capability
  • G.8032 ERPS, MSTP/RSTP/STP redundancy
  • Layer 3 static routing, robust management
  • Wide voltage input, redundant power
  • USB configuration and upgrading
  • Layer 2 features: VLAN, ERPS, STP/RSTP/MSTP
  • Management: Web, SNMP, CLI, Telnet/SSH
  • G.8032 ERPS support, fast recovery
  • Surge and ESD protection

RP-IPG63168IX-4FR is the highly reliable Layer 2+ managed industrial PoE switch with 16-port 10/100/1000Base-T PoE ,8-port 1000Base Combo and 4-port 1G/2.5G/10GBase-X SFP+. It delivers 30watts power per PoE port and generates a total of 370Watts power to PD devices, With full gigabit downlink and 10G uplink capability, it delivers high-performance data transfer across industrial networks.

RP-IPG63168IX-4FR supports G.8032 ERPS, MSTP/RSTP/STP redundancy technologies, Layer 3 static routing, and robust management features. With wide range voltage input 44-57VDC and redundant power design, it is ideal for large-scale industrial networks.

Robust IP40-rated rugged case protection with rack-mount installation, Its wide operating temperature ranges from -40°C to 75°C, RP-IPG63168IX-4FR is the best choice for heavy industrial factory, transportation, oil & gas, chemical, IP Surveillance and processing automation area where environmental conditions are harsh and critical.



RP-IPG63168IX-4FR 16-P Gigabit + 8-TP/SFP(1G) slot Combo + 4-SFP(1G/2.5G/10G) slot L2+ Managed Industrial PoE Switch
