10/100Base-TX to 100Base-FX Smart Media Converter
Model: RP-MC301 series
- 10/100Mbps auto-sensed
- Full-duplex and half-duplex auto-sensed
- Supports auto-sense of MDI/MDI-X
- LFP(Link Fault Pass-through) function
- Supports low-time lag transmission
- Supports transmission of long packets to 2048 byte
- Extremely low power consumption (less than 2W)
- Options in single mode or Multi-mode dual fiber
RP-MC301 series is a versatile Fast Ethernet Media Converter that seamlessly converts between 10/100Base-T and 100Base-FX networks. With various connector options and support for both single-mode and multi-mode media, it offers a cost-effective Ethernet-fiber link for extending network connections over a fiber backbone. Its simple plug-and-play design ensures easy installation in any environment.
RP-MC301 series features a DIP switch for enhanced smart function configuration. Administrators can enable or disable the Link Fault Pass-through (LFP) and Flow-Control functions. LFP (LLCF/LLR) promptly alerts administrators to link media issues and provides efficient network monitoring solutions. LLCF and LLR immediately detect and address link losses in both the TP line and fiber link. These functions help administrators proactively manage link media problems.
RP-MC301 series can be used as a standalone unit when powered by its DC adapter or seamlessly installed in the 14 Slot, 2U rack mount media converter chassis (RP-MCR314). This flexibility allows for centralized usage in a wiring closet, providing convenience and versatility for network setups.
- 10/100Mbps auto-sensed, facilitating network upgrade
- Built-in efficient switching core to implement flow control and reduce broadcast packets
- Full-duplex and half-duplex auto-sensed
- Supporting auto-sense of MDI/MDI-X, facilitating system commissioning and installation
- LFP(Link Fault Pass-through) function
- Supporting the transmission of 100Base-FX or STM-1, compatible with other devices
- Supporting low-time lag transmission
- Supporting the transmission of extra-long packets up to 2048 bytes
- Extremely low power consumption (less than 2W), reliable and stable performance
- Options in single mode dual fiber or Multi-mode dual fiber
Standards |
|
Wavelength |
|
Transmission distance |
|
Interface |
|
Dip Switch |
|
Conversion means |
|
Buffer space |
|
Flow control |
|
LED indicators |
|
Power Consumption |
|
Power Supply |
|
Operating Temperature |
|
Operating Humidity |
|
Storage Temperature |
|
Dimension |
|
Certification |
|
RP-MC301SC | 10/100Base-TX to 100Base-FX Smart Media Converter, MM/SC-2km |
RP-MC301C20 | 10/100Base-TX to 100Base-FX Smart Media Converter, SM/SC-20km |
