- Complies with IEEE 802.3 10Base-5/2/T Standards
- Transmission Rate : 10Mbps
- Topology: Tree (backbone and star)
- Access Method: CSMA/CD
- Provides up-link port for cascading
- Plug-and-Play design, no software configuration is required
- Auto-detection for bad port partition and auto-recovering
- NE-2000 compatible
- LEDs (Link/Activity/Partition) for monitoring operation status
- 19" rack mount width
- With internal universal power supply
- FCC CLASS A, CE
-
| Protocol |
|
| Topologies |
|
| Data Transfer Rate |
|
| Power Supply |
- Internal Power supply 100~240VAC, 50/60 Hz
|
| Power consumption |
|
| Environment |
- Operating Temperature: 0°C ~ 55°C
- Operating Humidity: 10% ~ 90%
|
| Dimension |
|
| Certification |
|
