RP-IP2105


RP-IP2105
4-P Broadband Router

  • RP- 4-P Broadband Router provides you an easy and stable way to share your Cable/DSL high speed Internet connection.

    The built-in NAT technology can act as a firewall to protect your internal network against outside hackers.

    The Router is compatible with most popular operating systems, such as Windows, Linux, Macintosh, etc.





    • Integrate with 4 ports Fast Ethernet switch: 10/100Mbps MDI/MDIX auto-sensing
    • Provide 1*10/100Mbps WAN interface to connect with DSL or cable modem for broadband Internet access
    • Support different Internet connecting modes: PPPoE, DHCP Client and Static IP PPTP
    • Built-in NAT (Network Address Transfer) technology acts as a firewall to protect internal sources against outside hackers
    • Support UPnP, Windows XP can find the Router in the network automatically
    • Simple, intelligent, web-based management and configuration interface
    • Support DHCP server to retrieve TCP/IP settings automatically from the Router
    • Support virtual server which makes LAN services (such as FTP, WWW, TELNET, DNS, etc) to be accessible to the Internet users



  • Standards

    • IEEE802.3 10Base-T, IEEE802.3u 100Base-TX

    Interface

    • 4-P * LAN, 1-P * WAN

    Management

    • Web-based

    WAN Type

    • Static IP Address
    • Dynamic IP Address (DHCP Client)
    • PPPoE
    • PPTP

    Connection Scheme

    • Connect on Demand/Auto-Disconnect
    • Manually Connect/Disconnect
    • Auto Reconnect

    NAT Function

    • One-to-Many NAT
    • One-to-One NAT
    • Virtual Server
    • DMZ Host

    Access Control

    • MAC-level Access Control
    • Domain Access Control

    Event Logging

    • On-web logging
    • Syslog supported

    LED Indicators

    • System, Link/Activity

    Power Supply

    • External power Adapter DC9V, 500mA

    Environment

    • Operating Temperature: 0°C~ 50°C
    • Operating Humidity: 20%~95% (Non-Condensing)

    Dimension

    • 160 * 83 * 26 mm

    Certifications

    • FCC, CE

  • RP-IP2105 4-P Broadband Router
